Feature:
Compact: Compact and portable design for advanced solid-state-laser technology.Touch-screen operations for easier use.
Precise: Continuously zoomed and precise laser spot size. omogeneous photocoagulation spot on retina.
Stable output but no power degeneration for closed-loop power control system.
Safe: Minimized power density on cornea.Maximum protection while maintaining clear field view.
Adaptable: Detachable delivery system, compatible with a range of slit lamp microscopes.
 |
 |
 |
 |
| Technical Data | |
| Treatment Beam | |
| Type | Diode-pumped frequency-doubled solid state laser |
| Wavelength | 532mm Green True CW |
| Power Output | 50~1200mW, adjustable |
| Pulse Duration | 0.01s~3s, adjustable |
| Pulse Interval | 0.05s~1s, adjustable |
| Aiming Beam | |
| Type | Laser diode |
| Wavelength | 630~680nm |
| Power Output | <1.0mW,adjustable |
| Cooling | Air Cooled, Thermoelectric Cooler System |
| Laser Delivery Unit | Slit lamp adapter |
| Slit Lamp Delivery | Haag Streit style slit lamp |
| Spot Size | Continuously adjustable from 50 to 500microns |
| Power | 100~240VAC |
| Size | 30cm×28cm×14cm |
