Feature:
Auto focus system, auto flash system, auto image optimization
Multipoint Internal fixation, double dots alignment
The image is more clear and solid, and the details are perfect
More precise and comfortable mechanical movement system
Automatic jigsaw: seamless splicing pictures, presenting the whole retinal image
Red free light: the retinal nerve fiber layer is observed, and the sensitivity is higher (optional)
Fundus color image.
 |
 |
 |
 |
| Technical Specification: | |
| Function | Non-mydriatic Color fundus photography |
| Camera | SLR Nikon D5200 (24.1 Mega Pixel) |
| Filed Scope | Up to 53° |
| Lens type | Aspherical |
| Minimum pupil diameter | 3.3mm |
| Observation Light Source | Infrared LED |
| Diopter compensation | ≥±15D |
| Fixation | External fixation + 5 internal fixation |
| Assisted Alignment | Two round dots alignment |
| Focus way | Auto Focus &Manual Focus |
| Exposure way | Auto Flash & Manual Flash |
| Internet Interface | Dicom 3.0 interface, LAN (Optional) |
| Eye position Recognition | Auto |
| Working distance | Horizontal ± 30°, up and down ± 12.5 ° |
