Feature:
Outstanding Optic Quality Ensure the Comfortable View
Parallel type, Galilean system
LED Illumination, long life time
Haag-Streit type slit lamp with broad beam,wide field and high depth of field.
3/5 step magnification
Interface for laser and applanation tonometer reserved
 |
 |
 |
 |
| Technical Data | |
| Model | SV-3, SV-5 |
| Illumination Type | Haag Streit Type |
| Illumination Source | Imported LED |
| Microscope Type | Parallel type, Galilean system |
| Magnification changer | Revolving drum |
| Eyepiece | 12.5X |
| Magnification | 10X 16X 25X (S3); 6X 10X 16X 25X 40x (S5) |
| Visual field Diameter | 6X:33mm10x:22mm 16X:14mm 25X:8.5mm 40X:5.5mm |
| Diopter adjustment | -7D~+7D |
| Pupil range | 52mm~82mm |
| brightness | continuously adjustable |
| Slit image width | 0mm~14mm continuous |
| Slit image length | 1mm~14mm continuous |
| Slit image angle | 0~180 continuously rotation |
| illumination tilting | 5◦ 10◦ 15◦ 20◦ |
| Slit aperture size | ф14 ф10 ф5 ф3 ф1 ф0.2 (mm) & 1~14mm continuously |
| Filter | Heat absorption, Grey, Redfree(Green), Cobalt bule |
| Fixation | Red LED 3.5V |
| Max Illumination | 600000 Lux |
| Background illumination | None |
| Input voltage | 70VA |
| Input power | 100V~240V 48~62HZ |
