Feature:
Contour design elegant;
With Sphere fast rotating disk, enabling the rapid adjustment of 3.00m-1.
The unique Cross Cylinder design, convenient and flexible.
Can be easily used to measure near visual acuity.
 |
 |
| Technical Data | |
| Sphere | -29.00 ~ +26.75D (step: 0.25D / 0.5D / 1D / 2D / 3D) |
| Cylinder | 0.00 ~ 8.75D (step: 0.25D / 0.5D / 1D / 2D / 3D) |
| Cylinder axis | 0 ~ 180° (step: 1 / 5 / 15 / 30 / 45°) |
| PD | far: 48 ~ 80 mm close: 45 ~ 75 mm (step: 0.5/1.0mm) |
| Working distance | 35 ~ 70 cm (step: 5 cm) |
| prism | 0 ~ 20 △ (step: 0.1△ / 0.2△ / 0.5△ / 1△ / 2△) |
| Jackson Cross Cylinder | Jackson Cross Cylinder0.25D Jackson Cross Cylinder0.50D 0.25D Dual Cross Cylinder (separation prism) |
| ophthalmoscope | +1.5D, +2.0D (measuring distance 67cm, 50cm) |
| Pinhole lens | Ф 1mm |
| Maddox | Right (red/horizon),left(red/vertical)) |
| Red and green lens | Right(red)left(green)) |
| Polaroid | Right(135°, 45°),left(45°, 135°) |
| Separation prism | Right (6△BU),left (10△BI) |
| Solidsuprachiasmatic cylinder: | 0.50D |
