SV-6D Digital Slit Lamp

Model: SV-6D

High Quality and High Image Resolution Digital Slit Lamp

Send Inquiry
WhatsApp: +86-15730269418

Feature:
Outstanding Optic Quality Ensure the Comfortable View
Precision Machining Makes the Smooth and Flexible Movement
Professional & Multi-functional Software With Simple Humanized
Human-computer Interface & Easy Operation
Have both image capturing function and video capturing function
Image processing for better Symptoms Diagnose
Backup patient data base easily guarantee data safety
Highest Quality Images Captured Which Impressive Every User
Aspecial designed black cross in right eyepiece which enable to synchronise the image
sharpness in eyepiece



Technical Data
Microscope Type Parallel
Magnification changer Revolving drum
Eyepiece 12.5X
Illumination Source Imported LED
Max Illumination Intensity 60000 Lux
Total magnification 6X 10X 16X 25X 40X
Diameter of Vision field φ37 φ23 φ14 φ8.7 φ5.7mm (φ23 φ14 φ8.7optonal)
Diopter  adjustment -7D~+7D
Slit image width 0mm~14mm continuous
Slit image length 1mm~14mm continuous
Diameter of aperture Ф14mm Ф10mm Ф5mm  Ф3mm Ф1mmФ0.2mm
Slit angle 0~180 continuously rotation
Illumination tilting 5◦ 10◦ 15◦ 20◦  totally 4 step
Filter Heat absorption, Grey, red freer(Green), Cobalt blue
Illumination 12V 50W Halogen Bulb
Fixation Red LED 3.5V
Power In put votage100~240V
